Machine size — 930x400x690 mm
Packing size — 930x410x710 mm
Weight — 59 kg
Rotator seats — Yes
Working area — from 75x75 to 300x300 mm
Installation type — Bench-type
Packing size — 930x410x710 mm
Weight — 59 kg
Rotator seats — Yes
Working area — from 75x75 to 300x300 mm
Installation type — Bench-type
Materials — Wood, Copper, Leather, Stone, Plastic, Cardboard, Aluminium, Plexiglas (Acrylic), Plywood, Glass, Brass, Stainless steel
ZnSe lens — F-Theta M85
Laser type — JPT
Laser output frequency — 20-150
Source power — 3/5/10/15 W
Wave length — 355 nm
Laser source life — >12 000-14 000 h.
Laser type — JPT
Laser output frequency — 20-150
Source power — 3/5/10/15 W
Wave length — 355 nm
Laser source life — >12 000-14 000 h.
Table model — Static
Marking speed — 7000
Cooling — Water
Engraving speed — up to 7000 mm/s
Marking speed — 7000
Cooling — Water
Engraving speed — up to 7000 mm/s
Controller — BJJCZ Fiber-M
Electric power supply — 220 V
Software — EzCad 2
Control system — BJJCZ Fiber-M
Power consumption — 1500 W
Supported format — AI, PLT, DXF, SVG, BMP, JPEG, GIF, PNG
Electric power supply — 220 V
Software — EzCad 2
Control system — BJJCZ Fiber-M
Power consumption — 1500 W
Supported format — AI, PLT, DXF, SVG, BMP, JPEG, GIF, PNG
Rotary device (optional) — Option
Laser beam diameter
Cylindrical marking
Easy to use
Emitter
Works with oversized workpieces
The machine is controlled by EzCad laser marking software.
Vector and raster image formats are supported.
The software has a built-in generator for marking and bar coding.
Vector and raster image formats are supported.
The software has a built-in generator for marking and bar coding.
30 times smaller than a CO2 laser and 3 times smaller than a ytterbium laser. This allows the UV marker to be used for ultra-precise colour or monochrome micro-marking on virtually all existing materials.
One of the most popular and widely used emitters on laser markers. Reliable and stable, it provides uniform filling suitable for both simple and complex applications.
The design of the machine allows the marking unit to be rotated to the desired angle and the stand to be locked in place, making it easy to work with oversized workpieces.
A rotary device can be fitted to the machine for marking cylindrical and similar shapes. The rotary device holds products even in fragile materials securely but gently without damaging them or leaving scratches on the surface.
The most versatile
works on any material
High detail
due to small beam diameter
High working speed
marking speeds up to 7000 mm/sec
Permanent markings
resistant to mechanical impact, cannot be erased
Wide range of colours and shades
choose your favourite shade depending on settings and material
Marks non-ferrous metals
Extremely reliable Environmentally friendly
Virtually everlasting marker if you do not intend to cut with it. The marker is not designed for cutting
Lack of consumables
Find an outlet and get to work. No consumables at all. Low power consumption
Non-contact application process
No need to fix the product during processing
Minimal risk of error due to human error
Machine programme runs independently
Runs 24 hours a day!
