Machine size (L * W * H) — 1610*360*680 mm
Weight — 75 kg
Weight — 75 kg
Emitter — Tongli
Emitter power — 50-80 W
Wave length — 1064 nm
Emitter power — 50-80 W
Wave length — 1064 nm
Marker type — Table type
Cooling type — Water
Emitter life — 6000-10000 h
Marking speed — 7000 mm/s
Desktop type — Lifting
Working temperature — 15-35 С°
Protective case — No
Pedal — Yes
Cooling type — Water
Emitter life — 6000-10000 h
Marking speed — 7000 mm/s
Desktop type — Lifting
Working temperature — 15-35 С°
Protective case — No
Pedal — Yes
Controller — LMCUSBv1
Software — EzCad 2
File formats — PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG, PCX
Power supply — 220 V
Power consumption — 700 W
Software — EzCad 2
File formats — PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG, PCX
Power supply — 220 V
Power consumption — 700 W
Rotary device — Option
Auto focus (Z axis) — Option
Auto focus (scanner) — Option
Smoke extractor — Option
Auto focus (Z axis) — Option
Auto focus (scanner) — Option
Smoke extractor — Option
Small size
Large diameter lens with a choice of area size
Training in marker operation
Easy use of a rotary device
Different types of emitters available
Genuine SinoGalvo scanner
Wattsan marking machines have an easy-to-use rotary device. With this you can process
Wattsan laser markers are equipped with two lenses (85 mm and 79 mm), what makes the equipment universal
Three types of emitters are available: IPG/Raycus/Max photonics. Each of these laser sources guarantees a high quality marking therefore you should choose the most suitable depending on your budget and production tasks
Wattsan always carefully selects manufacturers of machine tool components. The SinoGalvo scanner and EzCad software are guaranteed to unlock the full potential of laser sources
An undoubted advantage is the possibility to learn how to work on a marking machine. Our experts will explain and demonstrate all the marking features
The dimensions of the machine allow it to be used in the office or in the home workshop. All the necessary elements are already supplied, and there is no need to buy extra accessories
