Weight — 235 kg
Machine size — 1075x664x1055 mm
Packing size — 1270x700x1280 mm
Welding head weight — 0.8 kg
Fiber length — 10 / 15 m
Machine size — 1075x664x1055 mm
Packing size — 1270x700x1280 mm
Welding head weight — 0.8 kg
Fiber length — 10 / 15 m
Weld depth — 2 / 3 / 5 / 7
Operating humidity range — 30-70 %
Laser source — JPT
Laser wavelength — 1080 nm
Cooling — water
Focal length — 150
Operating temperature range — 5-40 ℃
Laser power — 1500 / 2000 / 3000 W
Laser frequency — up to 20 kHz
Operating mode — CW
Operating humidity range — 30-70 %
Laser source — JPT
Laser wavelength — 1080 nm
Cooling — water
Focal length — 150
Operating temperature range — 5-40 ℃
Laser power — 1500 / 2000 / 3000 W
Laser frequency — up to 20 kHz
Operating mode — CW
Protective lens — 20x2
Control system — Relfar
Welding head — FWH20-D11C
Focal length — 150 mm
Mode setting — Yes
Collimator focal length — 50 mm
Control system — Relfar
Welding head — FWH20-D11C
Focal length — 150 mm
Mode setting — Yes
Collimator focal length — 50 mm
Drive type — step motor
Feeding speed — 80 mm/min
Length of wire guide — 10 m
Wire diameter — 3.0 mm
Feeding speed — 80 mm/min
Length of wire guide — 10 m
Wire diameter — 3.0 mm
Welding gun functions
Laser source
Control desk
User-friendly interface for creating quality welds. The wide range of settings makes all types of welding patterns accessible even to the novice user. It takes about one day to learn how to operate and maintain the machine! The touch panel is dust-proof and remains operable under all circumstances.
The machine is equipped with a high quality RECI fibre laser emitter however, other brands are also available: IPG, Raycus, and JPT. The service life of a fibre laser emitter is more than 100,000 hours. The choice of source depends on the customer's wishes and required tasks. To weld large thicknesses including double-sided welding, IPG and Reci laser sources are preferred while any of the above brands can be used to weld thin metals.
The machine software allows you to change the joint thickness and welding patterns: circular, square, C-pattern, V-pattern, figure 8, etc. For ease of use, an additional display on the handpiece shows the current settings.
